Pure Sinus-CPS Series

CPS series inverter with charger is a perfect combination with pure sine wave inverter, bypass transfer part and 3 stage batter charger.

About pure sine wave inverter, it’s more widely used in practical applications, including resistive load and inductive load. Resistive loads such as light bulbs, TVS, etc. Inductive load such as Induction cooker, etc. When the inductive load is switched on or off, the power generated will be 5-7 times larger than the rated power and exceed the rated voltage of the inverter. Using pure sine wave inverter are more stable.

CPS series inverter with charger have the features of bypass transfer part.

When the public power failure, it converts the battery’s DC to AC to support electrical appliance’s work. When the public power on, it automatically switched to use main power and charged the battery. Transfer time between bypass and inverter mode is less than 15ms, and the transfer mode do not influenced the appliance’s working when the public power off.

About charger mode, the CPS series inverter is auto 3 stage battery charging way. The first stage is constant current, it’s a rapid charge for the battery constant high current. The second one is constant voltage, this allows the battery to well absorb the charge and maximum battery’s life. The last stage is floating charge, after the batter charged to around 99% full.
